| Brand name | Blueway |
| Color | Grey or White |
| COP | 4.0~4.5 |
| Fan discharging | Vertical or Horizontal |
| Material | Galvanized Steel Powder Coated/Plastic/Stainless steel |
| Max/Rated temperature | 28℃/40℃ |
| Place of origin | Guangdong China |
| Products type | Swim Pool heat pump |
| Refrigerant | R410A |
| Application | Home,Villa,SPA, School, Hotels, Hospital |
| Product Keywords | swim pool heat pump,chiller water cooled,industrial water chiller |
| Model | SPCH-I-2.0S | SPCH-I-3.0S | SPCH-I-4.0S | SPCH-I-5.0S | SPCH-I-6.0S | SPCH-I-5S | SPCH-I-6S | SPCH-I-7S | SPCH-I-10S | SPCH-I-15S | SPCH-I-25T | |||
| HP | 2 | 3 | 4 | 5 | 6 | 5 | 6 | 7 | 10 | 15 | 25 | |||
| Power Supply | V/Hz/Ph | 220-240/50/1, 208-230/60/1 | 380-415/50/3, 208-230/60/3, 380-415/60/3 | |||||||||||
| Heating performance |
Heating (1): A26/19°C W26/28°C |
Heating capacity | kW/h | 2.5~9 | 3.0~12 | 4.0~17 | 5.0~20 | 6.0~24 | 5.0~20 | 6.0~24 | 7~28 | 9~38.5 | 12~59 | 24~116 |
| Power consumption | kW | 0.2~1.65 | 0.24~2.22 | 0.33~3.2 | 0.42~4.15 | 0.51~5 | 0.42~4.1 | 0.5~4.95 | 0.58~5.5 | 0.75~8 | 1~12 | 2~23 | ||
| COP | w/w | 12.5~5.45 | 12.5~5.4 | 12.1~5.31 | 11.9~4.82 | 11.76~4.8 | 12~4.9 | 11.9~4.86 | 12.1~5.1 | 12~4.81 | 12~4.92 | 12~5.04 | ||
|
Heating (2): A15/12°C W26/28°C |
Heating capacity | kW/h | 1.8~7.5 | 2.2~9.5 | 3~12.5 | 4~15.5 | 5~20 | 4~15.5 | 5~20 | 6~23.5 | 8~31 | 10~48 | 20~93.5 | |
| Power consumption | kW | 0.27~1.7 | 0.33~2.1 | 0.48~3 | 0.66~4 | 0.81~4.94 | 0.65~3.92 | 0.81~5 | 0.95~5.75 | 1.31~7.9 | 1.65~12.5 | 3.4~24 | ||
| COP | w/w | 6.7~4.4 | 6.67~4.52 | 6.25~4.17 | 6.06~3.88 | 6.17~4.05 | 6.15~3.95 | 6.2~4 | 6.32~4.1 | 6.11~3.92 | 6.06~3.84 | 5.88~3.9 | ||
| Cooling performance |
Cooling: A35/24°C W30/28°C |
Cooling capacity | kW/h | 2~5.5 | 3~7.5 | 5~10.5 | 7~12.5 | 7.5~14 | 7~12.5 | 7.5~14 | 8~17 | 15~25 | 18~38 | 36~72 |
| Power consumption | kW | 0.42~1.7 | 0.61~2.25 | 1~3.2 | 1.37~3.85 | 1.4~4.23 | 1.35~3.9 | 1.37~4.3 | 1.4~5 | 2.7~7.35 | 3.2~11.2 | 6.55~21.5 | ||
| EER | w/w | 4.76~3.24 | 4.92~3.33 | 5~3.28 | 5.1~3.25 | 5.36~3.31 | 5.19~3.2 | 5.47~3.25 | 5.7~3.4 | 5.56~3.5 | 5.63~3.39 | 5.5~3.35 | ||
| Ambient temp. range | °C | -7~46 | ||||||||||||
| Rated/Max.outlet water temp. | °C | 28/40 | ||||||||||||
| Rated water flow rate | m³/h | 3.8 | 5.2 | 7.3 | 8.6 | 10.3 | 8.6 | 10.3 | 12 | 16.6 | 25.4 | 50 | ||
| Rated pressure drop | kPa | 4 | 5 | 5 | 7 | 13 | 7 | 13 | 15 | 15 | 17 | 23 | ||
| Controller | - | Micro processor based digital wire controller with LCD display | ||||||||||||
| External cabinet | - | Galvanized steel with powder coating | ||||||||||||
| Compressor | Type | - | Rotaty | Scroll | ||||||||||
| Qty. | Nos. | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 2 | ||
| Refrigerant | - | R32/R410a | ||||||||||||
| Water heat exchanger | - | Titanium tube in PVC shell | ||||||||||||
| Water connection | Inlet&Outlet | inch | DN40 | DN40 | DN40 | DN40 | DN50 | DN40 | DN50 | DN50 | DN65 | DN65 | DN80 | |
| Sound pressure at 1m | dB(A) | 40~51 | 42~52 | 44~53 | 45~56 | 46~58 | 45~56 | 46~58 | 45~59 | 48~62 | 49~63 | 62~72 | ||
| Air discharge | - | Side discharge | Top discharge | |||||||||||
| Net dimension | W*D*H | mm | 950*380*610 | 950*380*610 | 1110*430*700 | 1100*430*800 | 1100*430*960 | 1100*430*800 | 1100*430*960 | 1050*400*1260 | 1100*480*1480 | 1400*525*1630 | 2000*950*2100 | |
| Net weight | kg | 43 | 45 | 54 | 70 | 90 | ||||||||
Industry-specific attributes
| Storage / Tankless | Storage |
| Type | Heat Pump Water Heaters |
| Application | Commercial, Hotel, Household, Outdoor |
| Power Source | Electric |
| App-Controlled | Yes |
Other attributes
| Voltage (V) | 220 |
| After-sales Service Provided | Field maintenance and repair service |
| Warranty | 1 Year |
| Capacity | 0 |
| Installation | Freestanding |
| Private Mold | NO |
| logo/pattern | Silk screen printing, Laser Printing, Hot Stamping, Inkjet Printing, UV printing, Heat-transfer Printing, 3D Printing |
| Place of Origin | Guangdong, China |
| Brand Name | Blueway |
| Model Number | SPCH2.5S |
| Housing Material | Galvanized Steel Powder Coated |
| Brand name | Blueway |
| Color | Grey or White |
| COP | 4.0~4.5 |
| Fan discharging | Vertical or Horizontal |
| Material | Galvanized Steel Powder Coated/Plastic/Stainless steel |
| Max/Rated temperature | 28℃/40℃ |
| Place of origin | Guangdong China |
| Products type | Swim Pool heat pump |
| Refrigerant | R410A |
| Application | Home,Villa,SPA, School, Hotels, Hospital |
Packaging and delivery
| Selling Units: | Single item |
| Single package size: | 145X145X145 cm |
| Single gross weight: | 68.000 kg |
